MC22 Series Self-discharge Electromagnetic Separator for Casting Sand and Waste Material Iron Removal
PRODUCT PARAMETERS
Description
MC22 Series Self-discharge Electromagnetic Separator
MC22 Series Self-discharge Electromagnetic Separator is designed for long-term operating shifts. It is equipped with a self-discharge function and can continuously remove magnetic tramp iron from bulk materials on conveyor systems.
According to the catalog information, this product produces an almost uniform magnetic field along the width direction. It is suitable for removing magnetic tramp iron and casting heads from molding sand, as well as empty cans, iron sheets, rubbish, ash furnace materials and furnace slag particles.
Applications
- Molding sand iron removal
- Casting head separation
- Waste and rubbish material handling
- Ash furnace material processing
- Furnace slag particle treatment
- Conveyor belt iron removal systems
- Recycling and waste treatment lines
Product Features
- Self-discharge electromagnetic separator for continuous iron removal operation.
- Designed for long-term operating shifts.
- Produces an almost uniform magnetic field along the width direction.
- Suitable for removing magnetic tramp iron from molding sand and waste materials.
- Continuous iron unloading belt helps discharge attracted magnetic material automatically.
- Can be installed above conveyor belt systems for industrial material handling.
- Different models are available according to belt width, erection height, voltage, power and working conditions.
Main Technical Data
| Model | Erection Height T (mm) | Belt Width (mm) | Voltage (V) | Power (kW) | A (mm) | B (mm) | C (mm) | D (mm) | G (mm) | H (mm) | I (mm) | Driven Power (kW) | Mass (kg) | Commutation Controlling Unit |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MC22-5035L | 140 | 400 | 110 | 1.02 | 2100 | 1100 | 1000 | 920 | 760 | 700 | 793 | 1.5 | 750 | SSTM-1.5D |
| MC22-7045L | 190 | 600 | 110 | 1.88 | 2200 | 1350 | 1030 | 1120 | 915 | 1100 | 768 | 1.5 | 1250 | Unclear from image |
| MC22-7085L | 200 | 650 | 110 | 2.6 | 2730 | 1775 | 1230 | 1148 | 915 | 1330 | 760 | 2.2 | 2150 | SSTM-3.1D |
| MC22-9060L | 230 | 650 | 110 | 2.9 | 2360 | 1410 | 1080 | 1370 | 1165 | 850 | 780 | 2.2 | 1920 | Unclear from image |
| MC22-11075L | 290 | 800 | 220 | 3.8 | 2980 | 1985 | 1450 | 1390 | 1375 | 1300 | 777 | 2.2 | 2660 | SSTM-6.2D |
| MC22-130140L | 400 | 1200 | 220 | 6.8 | 3650 | 2700 | 1700 | 1800 | 1575 | 1320 | 860 | 4 | 6100 | SSTM-9.3D |
| MC22-150110L | 370 | 1400 | 220 | 7 | 3250 | 2050 | 1550 | 2000 | 1775 | 1400 | 970 | 4 | 6900 | SSTM-9.3D |
Note: The technical data above is organized according to the visible catalog information. Some values in the commutation controlling unit column are partly cut off in the uploaded image, so unclear items are marked conservatively. Final model selection should be confirmed according to belt width, material type, material layer thickness, installation height and iron removal requirements.
